CURT 11755 Class 1 Vertical Trailer with Mount, 1-1/4-Inch Receiver, Select Mazda Miata

---

CURT class 1 trailer hitches are the lightest-duty hitches of our rear mount receiver lineup. They are engineered for reliability, welded together with quality steel and blasted clean for a smooth finish. Tested to meet the strict demands of the industry, this CURT class 1 hitch has a capacity to tow up to 2,000 lbs. of gross trailer weight and 200 lbs. of tongue weight. This means it can handle a variety of small trailers such as single-axle utility trailers, canoe and kayak trailers, dirt bike trailers and more. It can also accept a hitch-mounted cargo carrier or bike rack, making it a very useful addition to cars with limited cargo space (NOTE: Never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc).Class 1 hitches feature a 1-1/4 x 1-1/4 receiver tube opening and are typically mounted on compact cars, full-size cars and some smaller crossover SUVs, minivans and compact SUVs. This particular hitch comes with a vertical receiver tube and is designed to be a custom fit trailer hitch for the Mazda Miata (to verify your vehicle compatibility, see the CURT application guide at curtmfg.com). It features a square tube frame and comes with a hitch pin and clip, all necessary installation hardware and an old-style ball mount to fit the vertical receiver tube. Each CURT class 1 hitch is co-cured with a liquid Bonderite coating and a high-gloss black powder coat finish that provide a lasting defense against rust, wear and harmful UV rays.

• Made w/A Vehicle-Specific Design For A Custom Fit
• Tested For Safety In Accordance w/SAE J684
• Precisely Welded For Superior Strength And Fit
• Constructed w/A Vertical Receiver Tube To Accept An Adapter
• Protected By A Durable High-Gloss Black Powder Coat Finish
• Co-Cured In A Rust-Resistant Liquid Bonderite Coating
• Strengthened w/A Cast Welded Seamless Collar
• Equipped w/An Open-Back Receiver For Easy Cleaning
• Made in USA [may include imported hardware]

---

Information:

Class 1 Vertical Receiver Trailer Hitch with 1-1/4 Adapter with 3/4 Hole; Engineered with a vehicle-specific design for a custom fit; Concealed main body for OE look and seamless integration with the vehicle; Tested for safety in accordance with SAE J684; Precisely welded for superior strength and fit; Constructed with a vertical receiver tube to accept an adapter; Protected by a durable high-gloss black powder coat finish; Co-cured in a rust-resistant liquid Bonderite coating; Equipped with an open-back receiver for easy cleaning; Limited lifetime warranty (one-year finish, one-year parts); Made in USA (may include imported hardware)

---

Application Summary:

Year	Make/Model
1999-2005	Mazda Miata
